Specifications
| bizhub 226 | bizhub 206 | |||
| Type | Desktop Printer / Copier / Scanner | |||
|---|---|---|---|---|
| Copy Resolution | Scan | Main: 600 dpi × Sub: 600 dpi | ||
| Main: 600 dpi × Sub: 600 dpi | ||||
| Gradation | 256 | |||
| Memory Size | 128 MB (standard) | |||
| Original Type | Sheet, book, three-dimensional objects (max. 2 kg) | |||
| Max. Original Size | A3 or 11” × 17” | |||
| Output Size | Main unit (Universal paper feed tray): Width: 90 mm to 297 mm (A3), Length: 139.5 mm (5.5”) to 431.8 mm (17”) Multi Bypass Tray (MB-505): Width: 90 mm to 297 mm (A3), Length: 139.5 mm (5.5”) to 431.8 mm (17”) Additional Tray (PF-507): Width: 182 mm (B5) to 297 mm (A3), Length: 182 mm (B5) to 431.8 mm (17”) | |||
| Image Loss | 4 mm at each edge (top/bottom/right/left edge) | |||
| Warm-Up Time*1 (23°C, std. voltage) | 15 sec. or less | |||
| First Copy Out Time*2 | 6.5 sec. or less | |||
| Copy Speed (A4/Letter Crosswise) | Simplex | 22 ppm | 20 ppm | |
| Duplex | 15.8 ppm | 15.2 ppm | ||
| Copy magni cation | Fixed Ratio | Metric | 0.25/0.50/0.70/0.81/1.00/1.15/1.41/2.00/4.00 | |
| Inch | 0.25/0.50/0.64/0.78/1.00/1.21/1.29/2.00/4.00 | |||
| Zoom Ratio Set by Up/Down Key | 25% to 400% Adjustable in 0.01 steps | |||
| Paper Capacity(64 g/m2) | Main unit (Universal paper feed tray): 250 sheets (up to A3) Multi Bypass Tray: 100 sheets (up to A3) Additional Tray (PF-507) : 250 sheets (up to A3) | |||
| Max. Paper Capacity (64 g/m2) | 1,350 sheets | |||
| Paper Weight | Main Unit/Multi Bypass Tray | 64 g/m2 – 157 g/m2 | ||
| Additional Tray (PF-507) | 64 g/m2 – 90 g/m2 | |||
| Multi Copy Setting | 1-999 pages | |||
| Max. Power Consumption | 1,300 W (127 V only: 1,350 W) | |||
| Dimensions [W] × [D] × [H] | 607 × 570 × 458 mm | |||
| Weight | Approx. 28.2 kg (excluding TC/Developer) | |||
| Space Requirements [W] × [D] | Standard con guration: 570 × 570 mm With bypass tray extended: 928 × 570 mm Max. required space incl. maintenance space: 999 × 971 mm* * When Multi Bypass Tray extended When Paper Feed Tray pulled out. (Slide length: 397 mm) | |||
| Application Software | PageScope Net Care Device Manager & Plug-in LSU (Local Setting Utility) | |||
*1 The time required to start printing when then main power switch is turned from OFF to ON.
*2 A4 long edge feed full size/using the rst tray/scanning from the original glass surface.
*2 A4 long edge feed full size/using the rst tray/scanning from the original glass surface.
| bizhub 226 | bizhub 206 | ||
| Type | Embedded | ||
|---|---|---|---|
| Print Speed | A4 | 22 ppm | 20 ppm |
| Letter | 21 ppm | 19 ppm | |
| Resolution | |||
